Adapting the Tool: A Heritage Building Information Model (HBIM) of Nossa Senhora da Piedade de Caparica
Jesse Rafeiro a, Ana Tomé b
a Carleton Immersive Media Studio, Carleton University,
1125 Colonel By Drive Ottawa, ON K1S5B6, [email protected]
b Instituto Superior Técnico, Universidade de Lisboa,
Av. Rovisco Pais, 1 1049-001 Lisboa, [email protected]
Once a place of silence and solitary contemplation for a group of Franciscan friars known as Capuchos, Nossa Senhora da Piedade de Caparica (1558) today is in a state of confusion about the original configuration of its spaces. Following a major renovation project in the 1950s and a lack of documentation throughout its life, the convent seeks to better understand its past and its continued role within the municipality of Almada. Since no record drawings or descriptions of the building exist prior to the renovation, an interdisciplinary, mixed-methodological research approach was taken to generate a HBIM reconstruction of the convent. The HBIM will serve as a record of the building’s modifications across time as well as an as-found record of the building to date for use into the future.
This paper focuses on one aspect of this overall research project by presenting the modelling methods used to overcome the limitations of BIM software (Revit 2020) for heritage. Since the software was designed to facilitate the construction of new buildings, a high level of effort is needed to adapt the tool to fit the irregularities and asymmetries of heritage. Focusing on the ornate 17th century façade –subjected to years of weathering and renovation campaigns– along with the entranceway and choir of the church, this paper addresses techniques for modelling a range of conditions typical to those found in heritage in Portugal. The paper will address methods for modelling irregular geometries such as wall deviations, curved ceilings, inconstancies in wall profiles and methods for modelling custom window families from point cloud data.
Keywords: Virtual Reconstruction, Architectural Heritage, Heritage documentation, HBIM, Photogrammetry, Digital Modelling, 3D Printing, Capuchos Convents
